The discovery of a new form of ice could lead to an improved understanding of our planet’s geology. This could potentially help to unlock new solutions in the production, transportation and storage of energy.
Ice XVI, the least dense of all known forms of ice, has a highly symmetric cage-like structure that can trap gaseous molecules to form compounds known as clathrates or gas hydrates.
Clathrates are currently known to store enormous quantities of methane and other gases in the permafrost as well as in vast sediment layers hundreds of meters deep at the bottom of the ocean floor.
Because of the potential decomposition of the clathrates, having a better understanding of their properties has become a key priority.
In a currently published paper in Nature, scientists from the University of Göttingen and the Institut Laue Langevin (ILL) report on the first empty clathrate of this type, consisting of a framework of water molecules with all guest molecules removed.
Previously thought to be purely hypothetical, this empty clathrate plays an important role in our understanding of the physical chemistry of gas hydrates. Such research could help ease the flow of gas and oil through pipelines in low temperature environments, and open up untapped reservoirs of natural gas on the ocean floor.
In order to create the sample of Ice XVI, the researchers constructed a clathrate filled with molecules of neon gas, which they then removed by careful pumping at low temperatures. Using small atoms such as those of neon gas allowed the clathrate to be emptied without compromising its fragile structure.
In order to achieve this, the neon clathrate was pumped in a vacuum at temperatures in the area of 140° K, while neutron diffraction data was taken using the ILL’s state-of-the-art D20 diffractometer. The obtained images allowed them to confirm when the clathrate had been fully emptied, and provided a complete picture of the resulting structure.
As a stable solid composed entirely of molecules of H2O, the empty clathrate also represents a new phase of ice. Ice XVI is the 17th discovered form of ice, and is the least dense of all known crystalline forms of water.
It is also predicted to be a stable low-temperature configuration of water at negative pressures (the equivalent of tension, the opposite of compressive positive pressures), and is so far the only experimentally-obtained form of ice to have a clathrate configuration.
According to the 2007 World Energy Outlook, the total amount of methane stored within clathrates on the ocean floor far exceeds the economically exploitable reserves of “conventional” carbon in the form of coal, oil or natural gas left on Earth. These reservoirs are currently difficult to exploit, but form a domain of intense ongoing research.
